For sale: a set of Visaton FR 16 WP ceiling speakers, designed for installation, background music, and PA applications. Visaton is well known for its reliable German-made loudspeaker components, and the FR 16 WP series is valued for clear speech reproduction and durable construction, suitable for fixed installations.
Condition:
The speakers are in minor damaged condition due to age.
-
Cosmetic wear consistent with long-term installation
-
Light scratches and signs of use
-
No major cracks or structural damage
🔊 Functional status
''Important note when tested: When we find there's either a small thing wrong, or not 100% working we offer our listings for parts or repair to avoid unwanted issues after purchase''
Specs:
Rated power 30 W
Nominal impedance Z 4 Ohm
Frequency response 60–15000 Hz
Mean sound pressure level 86 dB (1 W/1 m)
Opening angle (-6 dB) 46°/4000 Hz
Excursion limit 3 +/- 0.65 mm
Resonance frequency fs 85 Hz
Magnetic induction 1.0 T
Magnetic flux 250 µWb
Height of front pole-plate 4 mm
Voice coil diameter 20 mm
Height of winding 5.3 ±0.4 mm
Cutout diameter 143 mm
Net weight 0.46kg
D.C. resistance Rdc 3.7 Ohm
Mechanical Q factor Qms 2.99
Electrical Q factor Qes 1.55
Total Q factor Qts 1.02
Equivalent volume Vas 10 l
Effective piston area Sd 130 cm²
Dynamically moved mass Mms 8.4 g
Force factor Bxl 3.2 Tm
Inductance of the voice coil L 0.4 mH
Colour weiß / white
Connections 4.8 x 0.8 mm (+)/2.8 x 0.8 mm (-)
Protective system IP 65 *) IP 67 *)
Temperature range −40 ... 80 °C
Dimensions (LxWxH): 40x20x7cm
Weight: 1 Kg
Working condition: Fully working (See pictures for the cosmetic condition of this lot)
Missing or damages: Minor Marks
Does not come with fixed/factory power cable.
We ship worldwide.
Will ship to the USA as well. We ship DDP bases (Delivery Dutie Paid)
-Shipping in the EU up to 30 KG (max)
-Shipping outside of the EU up to 20 KG (max)
Please note: ‘’Whenever an item exceeds the weight noted above. Please ask for a shipping quote before making a purchase. The shipping costs are estimated in our shop because we do not know the shipping address.
Picking up the item is also possible. It can be picked up in Alkmaar
Delivery by us is also possible in some cases. Please reach out to us for more information about deliveries
State of listing: If a listing is listed ''for parts or not working'' returns are not accepted.
When we offer our products with the notice ''Serviced'' or ''Fully serviced'' that means the device is either lightly ''serviced'' with a new belt, and cleaned the pots, Or ''Fully serviced'' recapped, Quiescent current adjusted etc as expected from a full service
